Hitachi HAS-WM03 - Wall mount standard Hitachi A7 UST-projectors, included with most Hitachi UST-pj

Hitachi HAS-WM03 - Standard Wall Mount for Ultra Short Throw Projectors

The HAS-WM03 standard wallmount are included with most Hitachi UST-projectors avalible in the Nordic region

The Hitachi HASWM03 wall arm mount is designed to mount a Hitachi LCD projector on a wall. It features a high quality, ultra-durable construction and a long-life reliability.

The HASWM03 wall arm mount measures 274 x 315 x 472 - 803 mm with a throw distance of 104 - 409 mm. The wall arm mount has a weight capacity up to 10kg.

Mount a Hitachi LCD projector on a wall
Mounting your Hitachi projector on the wall above your interactive board is the best way to install it. This give you the best performance and shadow reduction as well as getting the projector up and out of the way. Never again will you have to worry about someone touching the projector or walking into it.

We recommend a 274cm from floor to ceiling so you have enough room above your board to mount the projector. It can work with 240cm from floor to ceiling, but you’ll need to hang the board lower on the wall, see mounting examples below.

MOUNTING EXAMPELS:
? 16:10 picture 89" diagonal (1920x1200mm BxH)
- Distance from floor to top of picture 2200mm (1000mm from floor to bottom of picture).
- Minimum distance from floor to ceiling 2810mm to get a perfect square picture without using keystone adjustment.
- Distance from top of picture to ceiling 610mm to get a perfect square picture without using keystone adjustment.
? 240cm distance from floor to ceiling with 16:10 picture 89" (1920x1200mm BxH).
- Distance from top of picture to ceiling 610mm to get a perfect square picture without using keystone adjustment.
- Distance from floor to bottom of picture will be 59cm.

For low ceilings there is an optional mount (HAS-WM05) avalible, it will need approx 10cm
less distance from top of picture to ceiling for the example above.

SPECIFICATIONS HAS-WM03:
? Swivel - +/- 3.0º
? Pitch - +/- 3.0º
? Roll - +/- 3.0º
? Throw Distance - 104 - 409 mm
? Max Load - 10 kg
? Height Adjustment - +/- 20 mm
? Side Adjustment - +/- 10 mm
? Dimensions - 274 x 315 x 472 - 803 mm (WxHxD)
? Weight - 5,8 kg
? Cable Management - Yes

HITACHI PROJECTOR COMPABILITY:
? CP-AX2503
? CP-AX3503
? CP-AW2503
? CP-AW3003
? CP-TW2503
? CP-TW3003
? And newer A7-models
